2206 mm (86 in) Rod Tine Style Skeleton Bucket
Application
Designed for screening debris from finer materials such as sand and loose soil, and for reclaiming rock and landscaping materials buried by sediment. Cat® Skeleton buckets are for use on both Cat Skid Steer Loaders and Compact Track Loaders.
Rod Tine Style Bucket
Rod tines are 32 mm (1.25 in) in diameter with 16 mm thick tine points improving breakout force by initially separating rock from soil more efficiently than a cutting edge.
Rock Dam
Rock dam improves material retention, reduces spillage and increases productivity.
Serrated Step
Serrated step ensures operator stability for entering and exiting the cab.
Wide Tine Spacing
Wide tine spacing allows for quicker screening and greater material separation.
| Product Specifications | |
|---|---|
| Width | 2206 mm (86.9 in) |
| Weight | 363 kg (800.3 lb) |
| Height | 644 mm (25.4 in) |
| Length | 1199 mm (47.2 in) |
| Sidewall Thickness | 10 mm (0.4 in) |
| Tine Spacing | 64 mm (2.5 in) |
| Tine Thickness | 32 mm (1.3 in) |
| Number of Tines | 22 |
| Interface Type | Skid Steer Coupler |
