1.03 m3 (1.35 yd3) Multi-Purpose Bucket, IT Coupler
Application
Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.
Bucket Design
Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.
Ground Engaging Tools
Base bucket also available with bolt-on cutting edge and bolt-on teeth.
| Product Specifications | |
|---|---|
| Width | 2406 mm (94.7 in) |
| Height | 973 mm (38.3 in) |
| Weight | 678 kg (1494.7 lb) |
| Length | 875 mm (34.4 in) |
| Capacity | 1.03 mu00b3 (1.35 ydu00b3) |
| Base Edge Thickness | 20 mm (0.8 in) |
| Cutting Edge Thickness | 19 mm (0.7 in) |
| Jaw Opening | 902 mm (35.5 in) |
| Clam Angle | 86 degrees |
| Interface Type | IT Coupler |
